DC24V IP67 RGB 0612 Silicone Led Strip ONE BIN only Dot Free DIY Connectors
DC24V IP67 RGB 0612 Silicone Led Strip ONE BIN only Dot Free DIY Connectors
DC24V IP67 RGB 0612 Silicone Led Strip ONE BIN only Dot Free DIY Connectors DC24V IP67 RGB 0612 Silicone Led Strip ONE BIN only Dot Free DIY Connectors DC24V IP67 RGB 0612 Silicone Led Strip ONE BIN only Dot Free DIY Connectors DC24V IP67 RGB 0612 Silicone Led Strip ONE BIN only Dot Free DIY Connectors

DC24V IP67 RGB 0612 Silicone Led Strip ONE BIN only Dot Free DIY Connectors

Product Details:
Place of Origin: China
Brand Name: JRLite OEM/ODM
Certification: UL / TUV / CE / ROHS / REACH
Model Number: LEDLINE ASTON 0612 RGB
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: On ESD Bag,on shipping box, without LOGO. Standard 5Mtr/reel, different lengths can be offered if needed.
Delivery Time: 3-4 weeks after payment
Payment Terms: D/P T/T Paypal
Supply Ability: IP20 LED strip 50000m per day
Contact Now

Detail Information
Model: LEDLINE ASTON 0612 RGB Entry: Front/Bottom/Side Entry
Material: Silicone Type: End Cap 2PIN
Dimension: 6mm X 12mm / 0.24" X 0.47" (W X H) Efficacy(lm/W): 14.8

Product Description

DC24V IP67 RGB 0612 Silicone Led Strip ONE BIN only Dot Free DIY Connectors



Quick Detail:

· Size 6mm x 12mm / 0.24" x 0.47" (Wx H)

· UV-resistance(no yellowish)

· IP67 rating

· Cable entry directions:Front/ Bottom/Side cable entry

· CE, RoHS, Reach, UL compliant

· Life Span >30000H

· 30 meters/reel available

· One bin only



Specifications:



Model
LEDLINE ASTON 0612 RGB
Certification CE, RoHS, Reach, UL
IP Grade IP67
LED PIN Temperature
Max. 65℃ /149o F
Storage Temperature
-25℃ /-13o Fmin, 60℃ /140o Fmax
Ambient Temperature
Tamin=-25℃ /-13o F, Tamax=45℃ /113o F
Power(W/m W/ft)
10/3.1
Efficacy(lm/W)
14.8
Max. Run Length
 5M





Download Datasheet: LEDLINE ASTON 0612 RGB Datasheet.pdf





Notices:

1. Please light it up for a quick check before
installation.
2. Bending diameter of LEDLINE ASTON 0612 RGB is 120mm, do not bend to upward or downward
direction, or bend too sharp or twist. If bend it wrongly, PCB inside will be damaged and the lighting fixture will not turn on.
3. During installation, please make sure there are at least two workers to cooperate together and strictly follow the instruction manuals.
4. Warranty: All LED light are warranted to be freefrom defects in product itself for 3 years from the date of purchase. This warranty does not cover failures due to abuse, misuse, improper handling, act of nature, negligence, normal wear, accidental damage, modifications or repairs made by the purchaser or incorrect voltage conditions.



Applications:

· Suitable for bar, ceiling and wall lighting application.
· Ideal for color dynamic application with excellent color rendition and high power levels.

DC24V IP67 RGB 0612 Silicone Led Strip ONE BIN only Dot Free DIY Connectors 0



FAQ:



Q1. How do you ship the goods and how long does it take to arrive?

A: Ship by DHL, UPS, FedEx or TNT. It takes 3-5 days to arrive. Airline and sea shipping also optional.



Q2. Is it OK to print my logo on led light product?

A: Yes. Please inform us formally before our production.



Q3. What are your payment terms?

A: 100% Payment before production or 30% deposit+ 70% before shippment(The latter requires a single payment of more than $10,000)



Q4. Do you have any MOQ limit for led light order?

A:Low MOQ, 1pc for sample checking is available.
